Cast Iron Radiator, Size: 4-7/16" Width x 25" Height x 38 1/2" Length - 22 Sections, 4 Tubes, Water/Steam, MR425X22

Cast Iron Radiators provide heat in a low profile package. Radiant heat combines with convected heat to shield outer walls and windows, thus stopping cold air infiltration into living spaces.

Cast Iron Radiator Spec Sheet

•  Free-standing
•  4 Tubes
•  22 Sections
•  Steam Output 10,560 BTU, Water 180 Degree Output 7,480 BTU
•  Lower and slimmer than most conventional radiators
•  Cast iron provides very quiet operation
•  Offered from 4 section up to 56 sections, which easily enables the installation of multiple units
•  Efficient radiator replacement option
•  Suitable for water or steam applications

SKU: MR425X22

Suggested Install Instructions:

When installing fittings to radiator, use a small amount of pipe dope or a small amount of Teflon tape (only once or twice around thread) on the fitting. Hand-tighten fitting into radiator. Using no longer than a 10" or 12" wrench, tighten it 1½ - 2 full turns. This is a suggested method only.

Included with all radiators is (1) 1 x 1/8" bushing, used for air valve installation.
