6" x 8" x 3/4" Elliptical Black Max Handhole Gasket - 6 Pack
Compared to spiral wound gaskets, BLACK-MAX gasket seal better and has much better recovery properties. And while spiral gaskets require near perfect conditions, BLACK-MAX gaskets seal on rough, pitted surfaces under less compressive load. Black-Max gaskets are made from multiple layers of foil-reinforced, exfoliated graphite and 316 stainless steel, ensuring gasket stability. The temperature range of the components and the recovery at broad temperature ranges (-400 to 1,200¬ˆ«F Steam) allow you to use them in virtually any situation, in environments from cryogenic to steam.
- Gaskets are 1/4" Nominal Thickness
- Temperature - -400¬ˆžF (-240¬ˆžC) to +850¬ˆžF (+454¬ˆžC) in atmosphere,+1200¬ˆžF (+650¬ˆžC) in steam
- Pressure (Max) 2000 psig (70 bar)
- P x T (max) 175,000 (6,000) 1/4"
- M Factor 2 (smooth Flange Surface)
- Y Stress 900 psi (6 MPa) (Smooth Flange Surface)
- Maximum Gasket Load 24,000 psi (165 MPa)
Material - Multi-Layer, High Strength 316SS Reinforced Graphite
